UserGate Virtual Firewall

UserGate can be deployed on the customer's virtual infrastructure. All hypervisors are supported, including VMware, Hyper-V, Xen, KVM, OpensStack, and VirtualBox. The functionality of our virtual solution is completely equivalent to that of the UserGate hardware system.

How to set up a virtual image?



Fast Deployment Time

The use of virtual infrastructure allows for high mobility and flexibility. A virtual image can be deployed in the shortest possible time. This can be essential both for initial installation and system recovery after a crash occurs.

Savings on Investments in Hardware

Virtual solutions work on the customer's existing infrastructure. At the same time, there is no need to purchase and support new expensive network equipment, and the risks that are associated with the sudden failure of any components are significantly reduced.

Scalability Without the Need to Change Hardware Platforms

Expanding resources that are already in-use or adding new virtual machines allows you to quickly scale up.

Convenient Configuration and Management of Security Policies

The use of a sample virtual image allows you to quickly install Internet gateways with certain security settings.

UserGate VE 100

Performance

Firewall throughput: up to 800 Mbps

IPS throughput: up to 600 Мbps

SSL inspection throughput: up to 50 Mbps

Advanced Threat Protection*: up to 150 Mbps

Stream-based antivirus throughput*: up to 150 Mbps

L7 application control throughput: up to 700 Mbps

Size of Organization

Recommended number of users**: up to 100

Equipment Specifications

10/100/1000Base-T ports: up to 8

10GBase-F SFP+ ports: up to 8 with VMXNET3 virtual adapters

Processor, number of cores: 2

RAM: 8 GB

HDD: from 100 GB and more

UserGate VE 250

Performance

Firewall throughput: up to 8 Gbps

IPS throughput: up to 1.3 Gbps

SSL inspection throughput: up to 300 Mbps

Advanced Threat Protection*: up to 1.3 Gbps

Stream-based antivirus throughput*: up to 1.3 Gbps

L7 application control throughput: up to 1.5 Gbps

Size of Organization

Recommended number of users**: up to 250

Equipment Specifications

10/100/1000Base-T ports: up to 8

10GBase-F SFP+ ports: up to 8 with VMXNET3 virtual adapters

Processor, number of cores: 4

RAM: 8 GB

HDD: from 300 GB and more

UserGate VE 500

Performance

Firewall throughput: up to 9 Gbps

IPS throughput: up to 1.35 Gbps

SSL inspection throughput: up to 320 Mbps

Advanced Threat Protection*: up to 1.5 Gbps

Stream-based antivirus throughput*: up to 1.5 Gbps

L7 application control throughput: up to 1.7 Gbps

Size of Organization

Recommended number of users**: up to 500

Equipment Specifications

10/100/1000Base-T ports: up to 8

10GBase-F SFP+ ports: up to 8 with VMXNET3 virtual adapters

Processor, number of cores: 6

RAM: 16 GB

HDD: from 300 GB and more

UserGate VE 1000

Performance

Firewall throughput: up to 10 Gbps

IPS throughput: up to 1.4 Gbps

SSL inspection throughput: up to 350 Mbps

Advanced Threat Protection*: up to 1.8 Gbps

Stream-based antivirus throughput*: up to 1.7 Gbps

L7 application control throughput: up to 1.8 Gbps

Size of Organization

Recommended number of users**: up to 1 000

Equipment Specifications

10/100/1000Base-T ports: up to 8

10GBase-F SFP+ ports: up to 8 with VMXNET3 virtual adapters

Processor, number of cores: 8

RAM: 16 GB

HDD: from 300 GB and more

UserGate VE 2000

Performance

Firewall throughput: up to 11 Gbps

IPS throughput: up to 1.8 Gbps

SSL inspection throughput: up to 600 Mbps

Advanced Threat Protection*: up to 2.5 Gbps

Stream-based antivirus throughput*: up to 2 Gbps

L7 application control throughput: up to 2.5 Gbps

Size of Organization

Recommended number of users**: up to 2 000

Equipment Specifications

10/100/1000Base-T ports: up to 8

10GBase-F SFP+ ports: up to 8 with VMXNET3 virtual adapters

Processor, number of cores: 16

RAM: 32 GB

HDD: from 300 GB and more

UserGate VE 4000

Performance

Firewall throughput: up to 11.5 Gbps

IPS throughput: up to 2.1 Gbps

SSL inspection throughput: up to 650 Mbps

Advanced Threat Protection*: up to 2.8 Gbps

Stream-based antivirus throughput*: up to 2.4 Gbps

L7 application control throughput: up to 2.8 Gbps

Size of Organization

Recommended number of users**: up to 4 000

Equipment Specifications

10/100/1000Base-T ports: up to 8

10GBase-F SFP+ ports: up to 8 with VMXNET3 virtual adapters

Processor, number of cores: 24

RAM: 32 GB

HDD: from 300 GB and more

UserGate VE 6000

Performance

Firewall throughput: up to 12 Gbps

IPS throughput: up to 2.4 Gbps

SSL inspection throughput: up to 700 Mbps

Advanced Threat Protection*: up to 3.1 Gbps

Stream-based antivirus throughput*: up to 2.7 Gbps

L7 application control throughput: up to 3.1 Gbps

Size of Organization

Recommended number of users**: up to 6 000

Equipment Specifications

10/100/1000Base-T ports: up to 8

10GBase-F SFP+ ports: up to 8 with VMXNET3 virtual adapters

Processor, number of cores: 32

RAM: 64 GB

HDD: from 500 GB and more

*Advanced Threat Protection includes filtering by UserGate URL Filtering 3.0 categories, morphological content analysis, stream-based antivirus, and ad blocking.

**The recommended number of users is determined based on the average employee profile. This value can vary widely depending on the kind of work performed by company employees and logging settings on the UserGate server.



Next-generation firewall

Intrusion Detection and Prevention System (IDS/IPS)

Advanced Threat Protection* (option)

Access to internal resources over SSL VPN portal

Security incidents info analysis and download (SIEM)

Reverse proxy

Automated response to cybersecurity threats (SOAR)

Application control L7

Mail Security**(option)

Internet access control

SSL decryption

Guest Internet hotspot

User identification

Virtual Private Network (VPN)

SCADA support

Remote administration

Safe publishing of internal resources and services

Bring Your Own Device (BYOD) concept support

High availibilty and clustering support

* Advanced Threat Protection includes filtering by UserGate URL Filtering 3.0 categories, morphological content analysis, cloud antivirus, and ad blocking.

** Mail Security includes cloud antispam, email antivirus, and support for methods of filtering unwanted email.
